€799,00 €1.295,00
TIC-21 Thermal Imaging Camera 220x160 Thermal Pixel with Wifi and PC Software
TIC 21 Thermal Imaging Camera 220 x 160 Thermal Pixel with Wifi
and PC Software
|
Parameter |
Specification |
|
|
Infrared Thermal Imaging |
Resolution |
220x160 |
|
Frequency band |
8~14um |
|
|
Frame rate |
9Hz |
|
|
NETD |
70mK@25°C (77°C) |
|
|
Field of view |
Horizontal 56°, vertical 42° |
|
|
Lens |
4mm |
|
|
Temperature range |
-10°C ~ 450°C (14°F ~ 842°F), can display to >600°C (1112°F) |
|
|
Temperature measurement accuracy |
±2°C or ±2% |
|
|
Temperature measurement |
Hottest, coldest, central point, zone area temperature measurement |
|
|
Color palette |
Tyrian, white hot, black hot, iron, rainbow, glory, Hottest, coldest. |
|
|
Zichtbare camera |
Resolutie |
640x480 |
|
Frame rate |
25Hz |
|
|
LED light |
Ja |
|
|
Display |
Display Resolution |
320x240 |
|
Display grote |
3.5 inch |
|
|
Foto mode |
Outline fusion (MSX), overlay fusion, picture-in-picture, infrared thermal imaging, visible light |
|
|
General |
Bedrijfs duur |
5000mah batterij, >4 hours in 25°C (77°F) |
|
Recharable battery |
ingebouwde batterij, aanbevolen +5V & ≥2A universele USB lader |
|
|
WiFi |
Support App and PC software data transmission |
|
|
Operating temperature |
-20°C~+60°C (-4°F ~ 140°F) |
|
|
Storage temperature |
-40°C~+85°C (-40°F ~185°F) |
|
|
Waterproof and dustproof |
IP54 |
|
|
Camera Dimension |
230mm x 100mm x 90mm |
|
|
Net weight |
420g |
|
|
Package dimension |
270mm x 150mm x 120mm |
|
|
Gross weight |
970g |
|
|
Storage |
Capacity |
Built-in memory, about 6.6G available, can store more than 20,000 pictures |
|
Picture storage mode |
Simultaneous storage of infrared thermal imaging, visible light and fusion images |
|
|
|
File format |
TIFF format, support full frame pictures temperature analysis |
|
Image analysis |
Windows platform analysis software |
Provide professional analysis functions to analyze full pixels temperature analysis |
|
Android platform analysis software |
Provide professional analysis functions to analyze full pixels temperature analysis |
|
|
Interface |
Data and charging interface |
USB Type-C(Support battery charging and data transmission) |
|
Secondary development |
Open interface |
Provide WiFi interface SDK for secondary development |
The package includes:
TIC-21 infrared thermal imaging handheld device * 1,
USB type C data cable * 1,
lanyard, product manual, warranty card.
