Features and Technical Specifications

• 8 Levels photocells for a better accuracy
• Three ‘’on grade’’ accuracies
• Constant reception accuracy regardless of operating distance, spot size and rotating laser type
• Min. operating rotating laser rpm: 300rpm
• Ultra bright indication with LED’s easy to view even in brightest sunlight
• Double stable bracket mounting
• Quick installation and easy mounting
• Detection range: 360°
• Operating range: 450m radius (depends on rotating transmitter)
• Operating voltage: 10-24V DC
• Operating temperature -15°C to +60°C
• Dimensions (mm): 162 (W) x 175 (D) x 272 (H) mm
• Weight: 2,3kg
• Waterproof and shock resistant IP65
